Petrel · 25 · Seismic structural interpretation
Fault-stick geometry displayed on orthogonal panels
Stage 25 of the Petrel sequence: fault traces and fault sticks are displayed on orthogonal seismic panels, with horizon offsets providing structural control.
Process stage
Fault traces and fault sticks are displayed on orthogonal seismic panels, with horizon offsets providing structural control.
Technical reading
The geometry is examined across adjacent sections before individual sticks are joined into fault surfaces.
Role in the modelling sequence
Fault picking, fault-stick construction and displacement control.
- Petrel
- Seismic interpretation
- Structural framework QC
Source record
Original figure caption: Fault-stick geometry displayed on orthogonal panels.
